Knee
1 mm Scissor Punch Series
SKU:
MP-225-800-532
| Item Description & Configuration | Jaw Size & Profile | Handle Type | Catalog / Order Number |
| Straight | 1 mm / Scissor Punch | Ring Handle | 225-800-532 |
| Straight Pro Handle Variant | 1 mm / Scissor Punch | Pro Handle | 225-700-532 |
| UpBiter | 1 mm / Upbiter Scissor Punch | Ring Handle | 225-800-535 |
| UpBiter Pro Handle Variant | 1 mm / Upbiter Scissor Punch | Pro Handle | 225-700-535 |
| UpBiter Left | 1 mm / Left-Angled Upbiter | Ring Handle | 225-800-537 |
| UpBiter Right | 1 mm / Right-Angled Upbiter | Ring Handle | 225-800-539 |
Accessories for Suction and Irrigation System (70 mm Working Length)
SKU:
MP-225-850-000
| Item Description | Key Features & Specifications | Catalog / Order Number |
| Irrigation Cannula Set |
• 1 stopcock • Includes trocar and obturator • 70 mm working length • Diameter: 2.3 mm |
• 225-850-000 |
| Irrigation Cannula Set |
• 1 stopcock • Includes trocar and obturator • 70 mm working length • Diameter: 3.5 mm |
• 225-850-001 |
| Blunt Obturator |
• 70 mm working length • Diameter: 2.3 mm |
• 225-850-002 |
| Sharp Obturator |
• 70 mm working length • Diameter: 2.3 mm |
• 225-850-003 |
| Blunt Obturator |
• 70 mm working length • Diameter: 3.5 mm |
• 225-850-004 |
| Sharp Obturator |
• 70 mm working length • Diameter: 3.5 mm |
• 225-850-005 |
Alligator Grasper Series (2.7 mm)
SKU:
MP-225-800-825
| Item Description & Configuration | Jaw Size & Profile | Handle Type | Catalog / Order Number |
| Straight Alligator Grasper | 2.7 mm / Short Jaw, Multi-Serrated | SlideLock Ring Handle | 225-800-825 |
| Straight Alligator Grasper Pro Handle Variant | 2.7 mm / Short Jaw, Multi-Serrated | Pro Handle (Non-Locking) | 225-700-825 |
| UpSwept Alligator Grasper | 2.7 mm / UpSwept Jaw, Multi-Serrated | SlideLock Ring Handle | 225-800-827 |
| UpSwept Alligator Grasper Pro Handle Variant | 2.7 mm / UpSwept Jaw, Multi-Serrated | Pro Handle (Non-Locking) | 225-700-827 |
ArthFLOWâ„¢ Sheath System (4.0 mm Telescope Series)
SKU:
MP-225-500-255
| Catalog ID | Item Name | Specifications | Clinical Application |
| 225-500-255 | Operating Sheath (30°) | 5.5 mm diameter / 2 stopcocks / Blue color code / 360° rotating system with telescope stabilizing | Fluid inflow/outflow management and precise telescope guidance specifically engineered for 30° rigid arthroscopes (4.0 mm) |
| 225-500-355 | Operating Sheath (Universal 0°/30°/45°/70°) | 5.5 mm diameter / 2 stopcocks / Blue color code / 360° rotating system with telescope stabilizing | Multi-angle fluid irrigation, suction, and stabilization accommodating universal 0°, 30°, 45°, and 70° telescopes (4.0 mm) |
| 225-500-555 | Blunt Obturator | 5.5 mm diameter / Blue color code / Designed for operating sheath | Atraumatic joint entry and smooth cannula introduction following initial puncture |
| 225-500-655 | Sharp Trocar | 5.5 mm diameter / Blue color code / Designed for operating sheath | Initial percutaneous tissue penetration and portal establishment into the joint space |
ArthFLOWâ„¢ Sheath System with Quick-Lock Specifications (5.5 mm)
SKU:
MP-225-550-255
| Item Description | Key Features & Specifications | Catalog / Order Number |
| Quick-Lock Operating Sheath |
• Quick-lock telescope locking mechanism • 2 stopcocks • Size: 5.5 mm • Color Code: Blue |
• 225-550-255 (for 30°) • 225-550-355 (for 0° / 30° / 45° / 70°) |
| Blunt Obturator |
• Designed for Operating Sheath • Size: 5.5 mm • Color Code: Blue |
• 225-500-555 |
| Sharp Trocar |
• Designed for Operating Sheath • Size: 5.5 mm • Color Code: Blue |
• 225-500-655 |
ArthVance Handgrip Instruments (Oval Curettes Series)
SKU:
MP-225-600-511
| Size | Dimensions (Thickness × Width × Height) | Angled Tip Configuration | Catalog / Order Number |
| Size 1 | $2\text{ mm} \times 3\text{ mm} \times 5\text{ mm}$ | 10° Angled Tip | 225-600-511 |
| Size 2 | $2.3\text{ mm} \times 4\text{ mm} \times 6\text{ mm}$ | 10° Angled Tip | 225-600-512 |
| Size 3 | $3.3\text{ mm} \times 6\text{ mm} \times 7\text{ mm}$ | 10° Angled Tip | 225-600-513 |
| Size 1 | $2\text{ mm} \times 3\text{ mm} \times 5\text{ mm}$ | 30° Angled Tip | 225-600-531 |
| Size 2 | $2.3\text{ mm} \times 4\text{ mm} \times 6\text{ mm}$ | 30° Angled Tip | 225-600-532 |
| Size 3 | $3.3\text{ mm} \times 6\text{ mm} \times 7\text{ mm}$ | 30° Angled Tip | 225-600-533 |
ArthVance Handgrip Instruments (Rasps Series)
SKU:
MP-225-600-610
Component & Catalog Specifications
1. Small Rasps (130 mm Working Length)
| Item Description & Configuration | Serration Type | Tip Profile | Catalog / Order Number |
| Small Rasp | Fine Serration | Straight Tip | 225-600-610 |
| Small Rasp | Fine Serration | Curved Tip | 225-600-611 |
| Small Rasp | Coarse Serration | Straight Tip | 225-600-612 |
| Small Rasp | Coarse Serration | Curved Tip | 225-600-613 |
2. Large Rasps & Special Variants (130 mm Working Length)
| Item Description & Configuration | Serration Type | Tip Profile | Catalog / Order Number |
| Large Rasp | Fine Serration | Straight Tip | 225-600-614 |
| Large Rasp | Fine Serration | Curved Tip | 225-600-615 |
| Large Rasp | Coarse Serration | Straight Tip | 225-600-616 |
| Large Rasp | Coarse Serration | Curved Tip | 225-600-617 |
| Convex Rasp | Fine Serration | Convex Profile | 225-000-505 |
ArthVance Handgrip Instruments (Spoons Series)
SKU:
MP-225-600-401
| Size | Spoon Dimensions (Width × Height) | Angled Tip Configuration | Catalog / Order Number |
| Size 1 | $3\text{ mm} \times 4.5\text{ mm}$ | 5° Angled Tip | 225-600-401 |
| Size 2 | $3.3\text{ mm} \times 5.5\text{ mm}$ | 5° Angled Tip | 225-600-402 |
| Size 3 | $4.3\text{ mm} \times 7\text{ mm}$ | 5° Angled Tip | 225-600-403 |
| Size 1 | $3\text{ mm} \times 4.5\text{ mm}$ | 25° Angled Tip | 225-600-411 |
| Size 2 | $3.3\text{ mm} \times 5.5\text{ mm}$ | 25° Angled Tip | 225-600-412 |
| Size 3 | $4.3\text{ mm} \times 7\text{ mm}$ | 25° Angled Tip | 225-600-413 |
ArthVance Handgrip Instruments (Two-Sided Curettes Series)
SKU:
MP- 225-600-521
| Size | Dimensions (Thickness × Width × Height) | Angled Tip Configuration | Catalog / Order Number |
| Size 1 | $2\text{ mm} \times 3\text{ mm} \times 5\text{ mm}$ | 20° Angled Tip | 225-600-521 |
| Size 3 | $3.3\text{ mm} \times 6\text{ mm} \times 7\text{ mm}$ | 20° Angled Tip | 225-600-523 |
| Size 1 | $2\text{ mm} \times 3\text{ mm} \times 5\text{ mm}$ | 30° Angled Tip | 225-600-541 |
| Size 3 | $3.3\text{ mm} \times 6\text{ mm} \times 7\text{ mm}$ | 30° Angled Tip | 225-600-543 |
Atrauma Grasper Series
SKU:
MP-225-800-850
| Item Description & Configuration | Jaw Size & Features | Handle Type | Catalog / Order Number |
| Atrauma Grasper (Non-Cannulated) | Cupped Jaw, Atraumatic Serrations | SlideLock Ring Handle | 225-800-850 |
| Atrauma Grasper (K-Wire Guide) | Cupped Jaw with Guide for K-Wires ($Ø 2\text{ mm} / 0.077\text{''}$) | SlideLock Ring Handle | 225-800-855 |
Backbiter Basket Punch Series (2 mm)
SKU:
MP-225-800-707
| Item Description & Configuration | Jaw Size & Direction | Handle Type | Catalog / Order Number |
| Backbiter (Left) | 2 mm / Left-Cutting | Ring Handle | 225-800-707 |
| Backbiter (Right) | 2 mm / Right-Cutting | Ring Handle | 225-800-709 |
| Backbiter (Left) Pro Handle Variant | 2 mm / Left-Cutting | Pro Handle | 225-700-707 |
| Backbiter (Right) Pro Handle Variant | 2 mm / Pro Handle | 225-700-709 |
Backbiter Basket Punch Series (Straight Configuration)
SKU:
MP-225-800-708
